UGREEN 7-in-1 USB-C Multifunction Adapter
KSh 4,500
- Brand: UGREEN
- Model: CM512
- Part Number: UG-90568
- Total Ports: 7
- Input: USB-C
- USB Ports: 2 × USB 3.0 (5Gbps)
- HDMI Output: 4K @ 30Hz
- Ethernet: RJ45 Gigabit (10/100/1000Mbps)
- Card Reader: SD & microSD (TF)
UGREEN 7-in-1 USB-C Multifunction Adapter Highlights
- 5 Gbps data transfer
- USB-C multiport hub hub type
- 2 × USB-A data port configuration
- USB-C PD charging port USB-C PD charging
- SD and microSD/TF slots card reader
- RJ45 Ethernet port ethernet
Compare UGREEN 7-in-1 USB-C Multifunction Adapter with Similar Products
Compare UGREEN 7-in-1 USB-C Multifunction Adapter specs, features and price with similar USB hubs and alternatives.
Comparison full
0 spaces availableUSB Hub
| Specification | UGREEN 7-in-1 USB-C Multifunction Adapter | UGREEN 7-in-1 USB-C Multifunction Adapter | Xiaomi 5-in-1 Type-C Hub | UGREEN 7-in-1 Multifunction USB-C Adapter |
|---|---|---|---|---|
| Brand / Model | UGREEN USB-C 7-in-1 hub (90568) | UGREEN 7-in-1 USB-C Hub (60515) | Xiaomi; 57780 | UGREEN Revodok 1071 (15214) |
| Hub Type | USB-C multiport hub | 7-in-1 USB-C hub | 5-in-1 USB-C hub | 7-in-1 USB-C hub |
| Host Connection | USB-C | USB-C | USB-C | USB-C |
| Port Configuration | 2 × USB-A data; HDMI; RJ45 Ethernet; SD and microSD; USB-C PD input | 7 ports: HDMI, USB-C PD charging, 2 USB-A data ports, Gigabit Ethernet, SD and microSD/TF slots | Three USB-A, one USB-C and one HDMI | 7 ports: HDMI, USB-C PD charging, USB-C data, 2 USB-A data ports, SD and microSD/TF slots |
Data
| Specification | UGREEN 7-in-1 USB-C Multifunction Adapter | UGREEN 7-in-1 USB-C Multifunction Adapter | Xiaomi 5-in-1 Type-C Hub | UGREEN 7-in-1 Multifunction USB-C Adapter |
|---|---|---|---|---|
| USB Data | USB 3.0 data connections up to 5Gbps | 2 USB-A data ports: up to 5Gbps | USB 3.0; theoretical 5Gbps rate | USB-C and 2 USB-A data ports: up to 5Gbps |
| Card Reader | SD and microSD/TF slots; two cards can be read simultaneously | SD and microSD/TF card slots | None | SD and microSD/TF card slots |
| Ethernet | RJ45 Ethernet port | Gigabit Ethernet | None | None |
Display
| Specification | UGREEN 7-in-1 USB-C Multifunction Adapter | UGREEN 7-in-1 USB-C Multifunction Adapter | Xiaomi 5-in-1 Type-C Hub | UGREEN 7-in-1 Multifunction USB-C Adapter |
|---|---|---|---|---|
| Video Outputs | HDMI display output | 1 HDMI output | 1 × HDMI | 1 HDMI 1.4 output |
| Multi-Monitor Support | 1 external display | 1 external monitor | 1 external display | 1 external monitor |
| Maximum Display Output | Not specified | Up to 4K at 60Hz | Up to 4K at 60Hz with compatible equipment | Up to 4K at 30Hz |
Power
| Specification | UGREEN 7-in-1 USB-C Multifunction Adapter | UGREEN 7-in-1 USB-C Multifunction Adapter | Xiaomi 5-in-1 Type-C Hub | UGREEN 7-in-1 Multifunction USB-C Adapter |
|---|---|---|---|---|
| USB-C PD Charging | USB-C PD charging port; 100W PD support | PD input: up to 100W; host output: up to 95W | None | PD input: up to 100W; host output: up to 95W |
| Power Requirements / Notes | Not specified | 5W reserved for hub; separate USB-C PD charger required for host charging | Up to 10W reserved for connected peripherals; USB-A output up to 5V / 1.5A | 5W reserved for hub; separate USB-C PD charger required for host charging |
Audio & Features
| Specification | UGREEN 7-in-1 USB-C Multifunction Adapter | UGREEN 7-in-1 USB-C Multifunction Adapter | Xiaomi 5-in-1 Type-C Hub | UGREEN 7-in-1 Multifunction USB-C Adapter |
|---|---|---|---|---|
| Audio / Hub Features | Not specified | Not specified | Plug and play; HDMI digital audio | Not specified |
Compatibility & Physical
| Specification | UGREEN 7-in-1 USB-C Multifunction Adapter | UGREEN 7-in-1 USB-C Multifunction Adapter | Xiaomi 5-in-1 Type-C Hub | UGREEN 7-in-1 Multifunction USB-C Adapter |
|---|---|---|---|---|
| Compatibility / Notes | Compatible USB-C computers and tablets; HDMI requires DisplayPort Alt Mode; mobile data requires USB OTG | Compatible USB hosts; individual functions depend on host hardware and operating system | Full-function USB-C hosts; DP1.4 or higher for 4K60 video; Windows, Android, macOS and Linux | Compatible USB hosts; individual functions depend on host hardware and operating system |
| In the Box | Not specified | Not specified | Hub and user manual | Not specified |
General
| Specification | UGREEN 7-in-1 USB-C Multifunction Adapter | UGREEN 7-in-1 USB-C Multifunction Adapter | Xiaomi 5-in-1 Type-C Hub | UGREEN 7-in-1 Multifunction USB-C Adapter |
|---|---|---|---|---|
| Brand | UGREEN | UGREEN | Xiaomi | UGREEN |
| Model | Not specified | Not specified | 57780 | Not specified |
Design
| Specification | UGREEN 7-in-1 USB-C Multifunction Adapter | UGREEN 7-in-1 USB-C Multifunction Adapter | Xiaomi 5-in-1 Type-C Hub | UGREEN 7-in-1 Multifunction USB-C Adapter |
|---|---|---|---|---|
| Dimensions | Not specified | Not specified | 112.5 × 10.4 × 39mm | Not specified |
Additional specifications
| Specification | UGREEN 7-in-1 USB-C Multifunction Adapter | UGREEN 7-in-1 USB-C Multifunction Adapter | Xiaomi 5-in-1 Type-C Hub | UGREEN 7-in-1 Multifunction USB-C Adapter |
|---|---|---|---|---|
| Material | Not specified | Not specified | Aluminium alloy casing | Not specified |
| Connector | Not specified | Not specified | USB-C host lead; three USB-A ports, USB-C port and HDMI | Not specified |
| Power | Not specified | Not specified | PD100W input; up to 90W laptop charging; USB-A output 5V⎓1.5A maximum | Not specified |
Product details
| Specification | UGREEN 7-in-1 USB-C Multifunction Adapter | UGREEN 7-in-1 USB-C Multifunction Adapter | Xiaomi 5-in-1 Type-C Hub | UGREEN 7-in-1 Multifunction USB-C Adapter |
|---|---|---|---|---|
| Video requirements | Not specified | Not specified | DP1.4 or higher host output; HDMI 2.0 or higher cable; suitable display | Not specified |
| Charging input | Not specified | Not specified | PD100W supported at USB-C power input | Not specified |
| Casing | Not specified | Not specified | Full aluminium alloy | Not specified |
| Operating temperature | Not specified | Not specified | 0°C to 35°C | Not specified |
Specs
UGREEN 7-in-1 USB-C Multifunction Adapter specifications
USB Hub
| Brand / Model | UGREEN USB-C 7-in-1 hub (90568) |
|---|---|
| Hub Type | USB-C multiport hub |
| Host Connection | USB-C |
| Port Configuration | 2 × USB-A data; HDMI; RJ45 Ethernet; SD and microSD; USB-C PD input |
Data
| USB Data | USB 3.0 data connections up to 5Gbps |
|---|---|
| Card Reader | SD and microSD/TF slots; two cards can be read simultaneously |
| Ethernet | RJ45 Ethernet port |
Display
| Video Outputs | HDMI display output |
|---|---|
| Multi-Monitor Support | 1 external display |
Power
| USB-C PD Charging | USB-C PD charging port; 100W PD support |
|---|
Compatibility & Physical
| Compatibility / Notes | Compatible USB-C computers and tablets; HDMI requires DisplayPort Alt Mode; mobile data requires USB OTG |
|---|
